Hose crimping can provide a safer, more reliable hose assembly than many other hose fitting attachment options. Ensuring you are taking the right steps to crimp your hose properly is of the utmost importance in regards to safety and system function. Follow these steps for proper hose assembly: 1. Select the hose, fittings and ferrules […]
Properly sizing a pump to specific application requirements is a complicated process. It accounts for many factors including fluid type, elevation changes, length/diameter of pipe, number of joints or bends, and requires some complex equations usually left to system engineers. If you already have a good idea of your flow and pressure requirements, however, pump […]
This mobile pump cart was designed for an adhesives manufacturer that needed to introduce additives and defoamer to an adhesive product. Due to systems already in place, the customer requested a mobile, turn-key solution that would offer minimal setup for integration. This assembly consisted of a Blackmer SX Series stainless steel vane pump coupled to […]
This fuel filtration skid was designed to filter underground fuel storage tanks that have become dirty/contaminated or contain large amounts of water. Our customer was wanting to pull up to fueling stations and have the ability to clean out their in-ground tanks with a variety of filtration capabilities. The final product is one of the […]
Global supply chain shortages prevented one of our customer’s bulk chemical supply from being delivered via railcar. They were able to purchase the chemical in 55-gallon drums as an alternative and needed a pump unit capable of line stripping to maximize product recovery. They also requested a run-dry capacity in the event a technician did […]
A Food & Beverage customer required a solution for low-flow, high-accuracy dosing of antioxidants into Canola Oil. This assembly consisted of a Pulsafeeder – Florida Blackline metering pump mounted on a painted carbons steel skid with associated stainless steel threaded suction and discharge piping. The suction and discharge piping included a y-strainer, pressure gauges, BLACOH […]
We recently had a customer deliver a pump for inspection after it had been sent to a third-party repair shop. When our technicians opened it up, they were shocked to find what was done in an attempt to repair the unit. It was immediately apparent that the pump was beyond repair based on the wear […]
The term “sealless pump’’ is used a lot in the transfer of fluids. The concept may be confusing if you are new to the industry. One can infer by the name that these are pumps that do not use traditional seal components, but what exactly does that entail, and what types of applications are ideal […]
One of our food production customers was paying $2,000 per week to have a third party pump out their used avocado oil, a byproduct of their production process. The oil would collect in a 10’ pit and they did not have an in-house solution for removal. Our team built them a mobile Wilden Pump Cart […]
One of our many value-added services is hose audits and hose management programs. As part of these services, our specialists conduct an on-site inspection to ensure all hoses are being properly used and maintained, which is crucial to their service life and to reduce the risk of failures in production. Additional (optional) services of the […]
Last month we discussed the internal operation of reciprocating pumps, one of two types of positive displacement pumps. This month we will analyze how the other type of PD pump – rotary pumps. Rotary pumps have rotating gears instead of the backward and forwards motion of cylinders like reciprocating pumps. In some cases, they can […]
Do you have a unique fluid fill process that needs to be addressed? We’ve shown other Fluid Fill Bowsers before – most recently a Windshield Washer Bowser. The one below is a Gasoline Bowser with a Wilden Pump and Engineering Air-Operated Double Diaphragm pump. This double diaphragm design will ensure precise amounts of gasoline are […]
A customer was no longer able to buy their chemical supply in bulk, causing them to use smaller totes. This created an issue in transporting the chemical throughout their facility, as the totes had to be stored in a location far from their previous bulk storage tanks and existing pump system. Anderson Process designed a […]
Chemical transports are one of the largest revenue streams for railroads in the United States. In 2019 close to 972 million tons of chemicals were shipped throughout the country due to their use in a diverse production of other goods. When transferring chemicals via rail car or tanker truck, the average capacity will be around […]
These three unique pump carts are used to dose precise small amounts of acids. The semi-automated, mobile units provide a highly efficient production output necessary for the chemical industry. These units feature a ¼” Wilden Accu-Flo AODD pump, ½” Wilden pulsation dampener, Polytrace B2 Batch controller, RTI filter regulator, Dixon ball valve, and spill containment […]
In a previous article ‘What Exactly Is a Positive Displacement Pump?’ we gave a high-level overview of different types of Positive Displacement Pumps. In this article, we will focus on Reciprocating Positive Displacement Pumps – how they work, advantages/disadvantages, and common applications in which they are used. As opposed to centrifugal pumps using impellers, the mechanical […]
Pictured below is a large skid we developed. The skid features a 10’’ BLACKMER® HXL10 vane pump coupled to a 161 HP diesel motor through a Nord Parallel shaft gear reducer. The gear shaft reducer was selected to handle the intense force and pressure applied, as the unit would be pumping fuel oil at 1650 […]
This uniquely orientated pump skid pictured below was designed to solve a couple of issues for a company transferring chemical solvents. Anderson Process mounted this Blackmer Pump on its side with a custom bracket built in-house, which allowed the pump suction to be at the top. This aided with its ability to drain as the […]
Pictured here is a custom filter cart built for a customer who wanted to remove the smell of ethanol in their facility. Featured on this 2-wheel cart is a Liquiflo Gear Pump with a flow rate of up to 3 GPM. Attached above the pump are 2 Shelco 20” filter housings furnished in 316 Stain-less […]
A custom skid we built for a customer that consisted of a 1-1/2” SS/Teflon Wilden Pump and Engineering pump, Blacoh AODD pulsation dampener, Blacoh SpillStop leak prevention system, RTI Eliminizer and air regulator, Bi-Torq ball valves, Continental Fortress air hose and Tudertechnica Glidetech hose. The discharge piping using on this cart was Schedule 80 with […]
Precise control mixing of materials can be a challenging feat. Understanding the chemical compatibility and how the liquid properties will react, blend, and change must be closely monitored. Pictured below are several different pumps and a control system we set up for a customer who needed to meter three liquids: propylene glycol, ethanol, and water […]
This 2” Wilden Pro-Flo Saniflo pump was mounted on a stainless steel cart that would replace the customer’s older Wilden Foodmaster. The Wilden Saniflo pumps are FDA approved and designed for standard food applications. They are typically used for processes that are moving high-acid, high-sugar, and high-fat media. This particular diaphragm pump is all stainless […]
Hose selection is critical to not only production output reliability, but also to user/environmental safety. Anderson Process’s comprehensive line of hose assemblies and hose fittings, combined with our maintenance-tracking and reconditioning support services, help our customers realize consistent and safe material containment, movement, and transfer. Pictured here are 2” Novaflex Red Uni-flon Composite hoses with […]
This custom skid features three Goulds Water Technology e-SV pumps designed to boost the flow of city water into production rooms for a food manufacturer. During the Summer months, the water pressure would drop significantly, and the customer had trouble providing consistent flow to the far side of the facility. This was especially problematic when […]
The often-forgotten and crucial component in a pump system is the mechanical seal, which prevents fluid from leaking into the immediate environment. Leaking mechanical seals due to improper maintenance or higher-than-expected operating conditions can be a hazard, housekeeping issue, health concern, or even an EPA issue. It is important to implement practices and conditions to […]
Don’t let old or worn-out seals hold your pump system back. Mechanical seals offer your rotating equipment the ability to be sealed in a cost-effective yet efficient manner. Mechanical seals contain the high pressurized fluid within pump vessels from the low pressured environment outside of the pump vessel. Our repair services can get your mechanical […]
We offer a variety of Fluid Fill Systems and Components that service automotive assembly plants and manufacturing plants. One of our portable offerings are called Bowsers, these Bowsers are portable fluid dispense systems containing hazardous and non-hazardous liquids. This system was a Windshield Washer Fluid bowser consisting of a Wilden Air Operated Double Diaphragm pump, […]
How to Pick the Proper Filtration Equipment Filtration is the process of removing any undesirable matter (solids or otherwise) from a process stream such as liquid or air. The incoming stream prior to filtration is called the effluent while the outbound stream after filtration is referred to as the filtrate. In any fluid-handling operation, filtration […]
This Cat high-pressure pump skid is used for flushing out cement drums commonly found on job sites or in cement mix plants. This is a triplex positive displacement pump meaning it has three plunger rods suitable for multi-gun and multi-nozzle high-pressure systems. It features max flow up to 15.6 gpm and a max pressure up […]
Our Michigan facility built several stainless-steel tanks to be used by an industrial laundry service company. They offer cleaning of tough, gritty materials such as oil absorbents, industrial towels, and floor mats that are used in various manufacturing facilities. They previously used polyethylene tanks in their facility to hold the materials used for their cleaning […]
We custom fitted a 1” Wilden Stainless Steel FDA pump on a heavy-duty stainless steel hand cart with an RTI filter regular and Continental hose for the air input to the pump. This Wilden Full Stroke Diaphragm pump was used to transfer FDA Oils and Ingredients. It was built on a cart to optimize it […]
A vacuum pump is a device that removes gas molecules or air particles from a sealed volume in order to achieve difference in pressure creating a partial vacuum. Vacuum pumps are designed in a variety of technologies based on the pressure requirements and the application it services. When setting up a vacuum pump system, sizing […]
Resins are naturally occurring as a plant substance but are often made synthetically, converted into polymers to be used in numerous applications. When pumping certain resins the biggest factor to consider is their viscosity, as they can vary from a thin syrup to a solid substance. Resins can be difficult to handle as they can […]
Two Envirogear E series pumps featured on this skid have unique superior design features to allow longer life cycles then other mechanically sealed or seal-less internal gear pumps on the market. What creates this distinct feature, the Between-the-Bearing System, a specially designed spindle that protects the rotor and idler gear from hydraulic force by supporting […]
When it comes to energy production, water plays a crucial role. Used as the main cooling source, it is a critical component in how these complex systems operate. Organic and inorganic substances in water create dissolved solids that along with other pollutants can cause buildup and corrosion. High-quality filters with high micron filter media, that […]
Industrial pumps and equipment operate in some of the most extreme working conditions. Over time certain physical impacts, moisture, chemicals, and ultraviolet light can cause corrosion and deterioration of parts, resulting in at worst a breakdown or at best a beaten down appearance. To combat this process Anderson Process offers powder coating finishes to skids […]
Often times, when creating, transporting or using chemicals, they require a great deal of care and they must follow strict guidelines. Finding the right equipment to handle such toxic and hazardous material is paramount to maintaining safe and accident-free conditions. A customer needed to keep antifreeze circulated through the tankers to keep the chemical from […]
We built a custom skid for a customer who needed to pump asphalt, a hot and aggressive material. Systems that handle these types of materials need to be able to handle unplanned disruptions in the system in regards to temperature and viscosity. Featured on this skid is a Blackmer 8” HXL sliding vane pump, a […]
Do clean welds get you excited? Part of a larger skids, these TIG welded piping components show the seamless integration of a engineered custom solutions to fit the needs of a unique fluid management system. Never compromise in optimizing your system.
One of the many reasons mechanical seals may need extra lubrication, include the high viscosity in certain fluids These pumps and mechanical seals may require the circulation of a clean fluid from an external seal flush. This process lubricates the inner and outer seal faces which separates the pumped fluid from entering the stationary housing […]
What special needs do you have for your filtration applications? Proper filtration enhances many industrial fluid applications, increasing the purification of water, chemicals, and other fluid output. Efficient filtration in markets such as automotive, food & beverage, chemical, pharmaceuticals, power generation, water and wastewater can save valuable resources that effect an organization’s bottom line. Anderson […]
Our capabilities extend beyond fluid handling systems. The Anderson Process shop crew is also proficient in custom fabrication to meet a variety of needs. Below is a large stainless steel motor control panel built for a global automation customer that needed to house outdoor motor & pump controls. The customer needed easy access to the […]
Here’s a large order we shipped out for a local candy manufacturer. These assemblies are Mouvex SLS1 Pumps coupled to Sterling Gearmotors. These pumps will be used to pump / inject oils and additives into the candy. Mouvex® SLS Series Eccentric Disc Pumps have been designed for use in a wide range of pumping applications […]
Anderson Process works with a wide variety of customers from food & beverage to automotive plants and beyond. Some of the less common industries that we serve include Waterparks, Zoos and Aquariums, which have ample opportunities for pumps and filtration. Some of our engineers and a territory manager recently worked with a local contractor to […]
We have shared many examples consisting of custom-engineered systems for our customers. It is rewarding to share the final result, but what all goes into the process to get to that point? Let us help break down the process on the last skid we built to give you an idea. Our engineering team handles requests […]
Here is a custom skid our team built for a customer that specializes in sustainable packaging. The customer needed a way to control the temperature of oil in a tank for use in their manufacturing process. To accomplish this, our team custom-engineered a skid using an assortment of fluid handling components from some of our […]
These Ampco ZP Pump Skids were built for a Dairy / Cheese Manufacturer that Anderson Process has serviced for many years. The skids are for an expansion in the facility, and are duplicates of pumps we have previously built for the same company as they continue to increase production. Over the years we have been […]
Our team recently built this custom cart for a customer that specializes in chemical handling and aerosol packaging. This duplex filter system is being used to filter a bentonite clay/water mixture in multiple locations, so it was fabricated onto a mobile cart to allow easy transfer around the facility. The cart was assembled with FTI […]
There are many different types of pump technologies that can be used for injection of different types of additives. The technology that is used for the addition of additives would depend on the types of flows, pressures, viscosities, chemical compatibility to name a few of the items that help us narrow down the proper pump […]
We have built a few of these carts over the years for a local Chemical manufacturer, this one that we just shipped out was no different. The pump assembly is used to transfer and recirculate an Aluminum / Solvent Slurry through a mill to reduce particle size. This pump was built on a cart so […]
We just shipped out some additional AMX Series pumps to an Aluminum Anodizing operation. These pumps are being used on the anodizing line for recirculating various bath / dip tanks full of various chemicals. Depending on the arrangement, the pumps could be piped in directly to the tank feeding various spray nozzles or jets, or […]
We recently built two custom pump carts for a local customer that manufacturers cleaning and sanitation chemicals. They wanted to minimize the amount of pumps needed and create a flexible solution for transferring chemicals from totes to a mixing tank to be blended for their customer’s specific needs. The pump carts needed to have a […]
We just finished a complete overhaul of a Sundyne LMV 811 API pump for a local Wisconsin Power Plant. Commonly found for pumping boiler feed water, condensate services or desuperheating, these pumps are key to keeping power plants up and running for power production. We did a complete rebuild of this pump, including a gearbox […]
Several years ago the Anderson Process team custom engineered a pump skid for a gravel pit customer moving large amounts of aggregate. The pump consisted of a large Pioneer GS8 Pump Assembly designed for pumping water 2,000 GPM at 60 Feet of head. The self-priming, solids handling, centrifugal pump was put on a fabricated steel […]
We recently had a customer that needed to build a temperature control skid that used a Dean pump to pump Therminol out of a storage tank and send it though a heating or cooling heat exchanger to control the temperature of the oil by the uses of control valves. The heating heat exchanger was a […]
This custom pump skid was designed for a Food & Beverage Chemical Manufacturer. On this project we modified a Wilden XPS15 Stainless steel FDA pump by adding a port to inject air on the underside of the inlet balls to keep them moving and allow the powder to work its way through the pump. The […]
Here are some pumps that were built for a food production facility, they are using Mouvex Eccentric Disc Pump assemblies for pumping Chocolate and Flavorings. The order consisted of 8 pumps total, ranging from an Mouvex’s largest SLS Series pump, the SLS36 that is designed for up to 158 GPM, down to their model SLS12, […]
One of our customers had the need to filter a viscous adhesive. We built them a custom filter skid compromising of two FTI housings arranged is a duplex orientation. The filters each have a pressure differential switch which allows the flow to be diverted once a filter gets too dirty to run. When the first […]
THE MOST COMMON TYPE OF PUMP USED FOR TRANSFER OF FLUIDS Centrifugal process pumps are one of the most common pump types used in industrial processing applications because they’re engineered to be low-maintenance, easy to operate and highly efficient. The fact that centrifugal pumps are the most popular choice for fluid movement makes them a […]
WHAT IS PUMP CAVITATION Cavitation is not a new phenomenon that impacts a pump system, but it is an issue that occurs far too often. It occurs when air bubbles are generated inside a pump because of the partial pressure drop of the flowing liquid, resulting in a tiny air bubble. The air bubbles move, […]
Proper hose and fitting selection are critical to the safety of both your people and your profits, thus why the S.T.A.M.P.E.D. acronym was created. The STAMPED acronym is an industry-wide standard that should begin every conversation when selecting a hose for a new application. STAMPED stands for: Size, Temperature, Application, Material, Pressure, Ends and Delivery. […]
Positive Displacement (PD) Pumps work by trapping a fixed amount of fluid, then displacing or forcing it into the discharge pipe. PD Pumps are engineered to use a reciprocating, rotary or diaphragm method to move a variety of fluids. These pumps are most commonly used for pumping viscous liquids and those that contain fragile solids. PD […]
Our repair capabilities extend beyond equipment designated for fluid transfer. After a municipality in Michigan purchased a small pump from Anderson Process, they inquired about our ability to re-finish a number of other items for them – including staircase railings, ladders, lamp posts, and park benches. Our in-house sandblasting and powder-coating capabilities made it easy […]
The Anderson Process Repair Team is capable of handling equipment in any condition. This Viking asphalt pump was delivered in rough shape. Our team performed a range of repairs including a new bracket bushing, idler gear & bushing, packing, gaskets, elastomers, bearing, and bearing retaining hardware. It was sandblasted, repainted, and now looking and operating […]
Magnetic Drive Pumps Mag Drive pumps are seal-less pumps that use the technology of a drive magnet and inner magnet connected to an impeller to move fluid through the pump. The drive magnet and inner magnet are separated by a rear casing or housing, creating a seal-less containment. A Mag Drive Pump will prevent the […]
One of our customers noticed the fluid end seals on their CAT high pressure pump were leaking, but decided to keep the pump running in order to get the job done. They did not notice the internal severity of the seal leak, and without a proper maintenance schedule the seals were never changed. The end […]
Anderson Process provides unrivaled support to the industries we serve. One of our customers came to us recently for help installing custom vent lines on their Goulds e-SV pump carts. They had been buying the modified pumps from a competitor, but were not happy with the support they were receiving. Our team was happy to […]
Finding New Uses for the Continental Fortress Hose! One of our long-time farming customers has used Continental Fortress washdown hose’s for years. The durability and abrasion-resistant cover had been a perfect fit for the harsh environment of farming applications, and the working pressure and chemical compatibility was more than enough to meet their washdown […]
Anderson Process supplies a gearbox re-manufacturing customer with new hose kits for a range of gearbox models. The re-builds usually consist of standard hose and components from our stock or easily sourced, but one of our last jobs for this customer presented a unique challenge. The gearboxes they were working on were manufactured in Europe […]
Safety, Simplicity, and Versatility. These are three terms that go hand-in-hand with Air-Operated Double-Diaphragm (AODD) Pumps. While no single pump type can be perfect for all applications, AODD pumps can cover a wide spectrum of applications and materials. Air-Operated Double-Diaphragm (AODD) pumps are a type of positive displacement pump that utilizes compressed air for a […]
Business is slow for many, but that doesn’t mean you can’t remain productive. If you have equipment sitting idle due to partial shutdowns, now might be a good time to perform preventative maintenance to ensure they perform as needed when full production returns. Small investments now can help you avoid significant damage on pumps and […]
Custom carts and skids are one of our main areas of expertise. Often times, multiple permanent filtering solutions are not a financial or efficient reality for our customers. As a solution, mobile carts can be kitted with the proper equipment and used in multiple locations depending on which system has the need at any given […]
Increasing output and efficiency is a common goal for all manufacturers. Customers often come to Anderson Process looking for ways to improve their fluid handling applications. Our experienced Territory Managers are there every step of the way, from initial walk-thoughs and recommendations to full implementation. Here’s another production improvement designed and coordinated by the AP […]
Activated carbon media, either in bulk or filter element form, has been shown to be effective in removing odor in applications where customers are using non-FDA grade ethanol and alcohol to produce hand sanitizers and bulk sanitizing agents for combating the COVID-19 virus spread. For proper filtration, the two key factors (challenges) while using activated […]
We’ve tested over 10,000 hoses in dozens of manufacturing facilities. The average failure rate of the hoses we test is 18%. That’s a lot of unwanted opportunity for safety issues, downtime, and inefficiencies in your process. Proper hose specification and maintenance are essential to consistent production output, efficient long-term fluid management and a safe and […]
In 2014, EMCO opened a new large-scale terminal facility that needed efficient, low-maintenance pumps. Because of the critical nature of these storage areas, it was imperative for EMCO to identify the right brand and style of pump that would be used to unload railcars of raw materials and load totes, drums and IBCs with finished […]
Anderson Process has recently worked with another customer to solve their fluid transport and storage needs. Challenge: The customer was looking to move from drum and tote delivery of ethyl acetate to a centralized storage system. Solution: Anderson Process provided them with 2 outdoor 5,200 gallon double walled tanks and 2 indoor 500 gallon double […]
We are more than a pump distributor. We work closely with customers to provide solutions to any fluid handling applications, extending well beyond standard pumps and hose. This customer needed increased storage capabilities for their operation and turned to Anderson Process for a solution. Challenge: Our customer needed to expand storage capabilities for increased production. […]
Mechanical seals keep the fluid contained within pumps while the internal mechanical components move inside the stationary housing. When mechanical seals fail, the resulting leaks can cause extensive damage to the pump and often leaves large messes that can be significant safety hazards. Besides being a crucial component to a pump running efficiently, it is […]
ACI Systems create semi-automated systems to dispense hazardous or non-hazardous liquids in small but precise amounts to test a large range of vehicles during the manufacturing process.
Do you crimp a lot of hose? Our program will allow you to use a new Hydraulic Crimper on-site for the cost of business as usual. Get your free hydraulic crimper from Anderson Process today!
Here is one of many style Gas Fuel Bowsers that our team custom built to be used on an assembly line to fill units that have missed the fuel station for any number of reasons. The unit is designed with a Wilden Pump, ground reel, level gauge and a Fill-Rite meter to dispense accurate amounts […]
These Gusher 7550 Series Vertical Centrifugal End Suction Pumps were used for pumping water at a manufacturing facility. After a couple performance issues, the customer called on Anderson to get a quote for repair. The repair team picked up the units at the customer facility and returned it to our warehouse for evaluation. A thorough […]
Anderson Process offers a comprehensive line of centrifugal and positive displacement pumps to provide pump systems that deliver reliable performance in demanding applications. Although the basic structure and operation of pumping systems hasn’t changed much over the years, industrial pumps remain a sophisticated piece of machinery, each with its own ideal operating conditions and application. […]
The pump is the heart of any fluid processing application. Properly specified pump drives output and directly impacts an operation’s bottom line. Unfortunately, pumps can fail at any given moment resulting in inefficient operation, equipment failures and production losses. So why do pumps fail? We had our in-house pump expert and seasoned sales representative, John […]
Anderson Process Fluid Fill Systems have been used worldwide to dispense fluids at flow rates that range from mils per minute to gallons per minute. We offer a variety of services such as assembly line fill, vapor recovery, chiller and heat exchanger systems, control panel design and build, portable pump systems, chemical blending systems, pharmaceutical […]
Hose safety often does not get the attention it deserves. Proper hose and fitting selection are critical to the safety of both your people and your profits. If a hose fails in a manufacturing or industrial processing operation, the entire production line becomes compromised, putting expensive equipment, product and lives at risk. Choosing the right […]
Click here to download our brewing solutions brochure! Anderson Process offers a full line of sanitary processing equipment engineered to optimize food safety, batch consistency and production efficiency.
Custom Solutions is a cornerstone of our business. We regularly create custom solutions for customers, ranging from simple skids for general use to elaborate pump systems that meet the need of very specific applications. This is an example of one of our larger projects where the customer needed a packaged solution to moving and treating […]
Proposition 65 requires businesses to provide warnings to Californians about significant exposures to chemicals that cause cancer, birth defects or other reproductive harm. These chemicals can be in the products that Californians purchase, in their homes or workplaces, or that are released into the environment. By requiring that this information be provided, Proposition 65 enables […]
John Vorpagel (Anderson Process) and Mike Solso (Envirogear Pumps) sit down to discuss mechanical seals, seal-less technology, and EnviroGear® E Series Magnetically Coupled Seal-less Internal Gear Pumps in their first video series, “2 Guys Talk About Pumps”. Check out the first series of short videos below: Face it, Mechanical Seals are Complicated There are […]
Click here to download our chemical solutions brochure! Anderson Process offers a number of products, all from industry-leading brands, as well as a number of value-added services designed to help counteract the problematic nature of chemical handling.
This Busch RA1600 was being used in a vacuum molding application. This unit’s purpose is to draw the molten plastic being injected into the process against the sides of the molds filling the cavity completely ensuring that the drainage tile is fully formed as it leaves the process. Inspection This unit arrived in pretty rough […]
Is mobility, cleanliness or filtration the most important part of your process? Let us help you combine it all into one package. Here we built an all stainless steel portable cart using a Wilden 1.5” Saniflo Hygienic pump to pump a personal hygiene product from bulk totes through a Shelco MicroVantage filter to their filling […]
Here we helped a customer build a series of chemical treatment recirculating skids that heated and filtered the chemical before it was sent off to the process. The overall system was designed for 75 GPM at 40 PSI. We utilized a Goulds 3756 centrifugal pump, Standard Xchange Plate & Frame heat exchanger, Eaton Filters, Dixon […]
Our repair team here at Anderson Process is uniquely positioned to deliver superior refurbishment and aftermarket services for even the most complex liquid process equipment challenges. Here are some pictures of two Total Control Systems (TCS) 682 Piston Meter rebuilds that were just finished. These meters came to us out of calibration and with worn parts after […]
Our fab shop crew built and assembled this for a transmission drain bench used in a lab for testing. Designed with 1/2″ Wilden pumps, stainless steel drain tanks with sight glasses and insulated for sound.
We designed and built a front differential gear oil fill system for an automobile company. The system uses two 1/2″ Wilden aluminum pumps, Burkert air operated valves, Numatics regulators, safe lockout valves, Graco oil fill nozzle and a needle valve for flow control.
Our fabrication team in Michigan just finished up a gas skid for an automobile manufacturer. The skid is going to be used for an addition to an existing line to increase production. We designed the gas skid with Parker filters, Total Control Systems (TCS) meters, Morrison fire safe valves, Numatics regulators, Ross solenoid valves and […]
Here we are finalizing the mechanical aspect of a unit designed for Gas and Oil fill at a small engines / power equipment plant in the Southeast US. The customer came to us with a manual process in place and we worked with them to automate the process the best we can. There is a […]
