Compact. Powerful. Purpose-Built. Take a look at this custom lubrication skid engineered by the Anderson Process team. The skid features: ā¢ Tuthill gear pump ā¢ Airex air-cooled heat exchanger ā¢ PowerGuard spin-on filter ā¢ Welded carbon steel SCH40 interconnection piping ā¢ Compact, painted carbon steel base Every component is selected and assembled to meet all […]
We recently built a custom skid for a chemical handling application, engineered for durability and efficiency. This system includes: ā Wilden air-operated diaphragm pump ā FTI filter housing ā Wilden pulsation dampener ā Blacoh gauge with Gauge Guard ā Bonomi actuated valve All components are securely mounted on a fabricated stainless steel square tubing frame […]
Engineered for Excellence! Hereās a sneak peek at one of our latest skids: featuring a Mouvex eccentric disc pump with a heating jacket, coupled to a Nord gear reducer and a Weg motor, all mounted on a painted carbon steel base plate. Why Mouvex Eccentric Disc Seal-Less Pumps? š¹ Seal-Less Design ā No magnets, packing, […]
Neptune Metering Skid: Built for Precision This skid, crafted for an industrial equipment manufacturer, is packed with top-tier components for reliable performance: š¹ (2) Neptune metering pumps š¹ Calibration column š¹ (2) Pressure relief valves š¹ Back pressure valve š¹ Pulsation dampener Everything is connected using SCH80 PVC piping and mounted on a durable polypropylene […]
We recently partnered with a research and design company to deliver a comprehensive solution for their fluid handling needs. Our team provided them with: 2 Liquiflo H-Series Stainless Steel Gear Pumps that feature Ā¾” inlet and discharge with a max flow rate of 10.7 gpm and a discharge pressure of 225 psi. ABB Baldor 1 […]
Recently, a chemical manufacturer reached out to us for a robust, reliable pumping solution. Ā Hereās what we delivered: Blackmer G1-32 Cast Iron Gear Pumps designed to handle demanding chemical applications, featuring steel internals and 2″ npt fittings on both inlet and discharge. Nord Gear Reducer paired with the pumps to ensure optimal performance and torque […]
We are always fabricating unique carts and bases to meet customer needs. While many look alike, they are almost always different. We have standard-sized pump bases in various lengths in stock, but once we start building wider or longer, we often need to fabricate custom bases. This 40″ x 30″ base was the foundation for […]
We recently built these two Cornell Pump STX-Series self-primer pump skids for pumping wastewater at a food processing plant. The 6″ STX-Series pump is designed to pump 800 gpm at 25 feet of head while the larger 8″ STX-Series pump is designed for 1,200 gpm at 25 feet of head. Both pumps were fabricated using […]
We built this uniqueĀ cart for a Continental PumpĀ progressive cavity pump out of carbon steel, which we painted with epoxy and mounted on 8″ rubber wheels. The pump is constructed of stainless steel, powered by a 2 hpĀ WEGĀ motor, with a Viton stator and coupled to aĀ NordĀ Gearbox. It provides 20 gpm at 50 psi of slurry. Additional […]
Just about everyone and everything needs a little support sometimes. We fabricated these (2) large, robust pump stands and belt guards for 8ā Cornell food handling pumps. The food and beverage customer supplied their own motor, belts, and pulleys. The customer was pleased with how supportive and strong these stands were. At Anderson Process we […]
Engineered for a chemical manufacturer, This HMD Kontro Mag-Drive Pump Assembly is one solid unit. Made of rugged Alloy 20 stainless steel to provide the best corrosion resistance in chemical environments and utilizing a severe duty Marathon motor (15 HP). The customer was looking for a pump skid that packed some punch and could handle […]
Anderson Process designs and builds custom skids and systems for fluid processing applications, which includes welding piping and sanitary tubing in-house. Check out this sanitary tubing we welded fittings on for a custom adhesive filtration skid we built. Welding sanitary tubing is a technical process that needs to have full penetration and purge gas flowing […]
Designed for a mixer manufacturer, this metering skid was built by Anderson Process to meter different additive liquids to cement during the mixing process. The skid was constructed using (3) poly tanks, (1) Liquiflo gear pump, (2) Viking gear pumps and Dixon and Jomar actuated 3-way valves. Anderson Process not only designs and builds metering […]
These Wilden Pro-Flo Shifts AODD pump stands were supplied to a chemical manufacturer for pumping a variety of different chemicals. The stands consisted of Wilden Pro-Flo Shift pump, IFC Y-Strainer, Wilden Pulsation Dampener (not pictured), Dixon air shut off valve, RTI air filter, coalescer, regulator, and (2) Hose Master Flex connectors (not pictured). The components […]
Pictured is a duplex pump skid that was designed for pumping fuel oil at a hospital. The assembly consisted of (2) Tuthill gear pumps, Fulflo relief valves, Dixon valves and a Titan duplex basket strainer. All the components are mounted on a painted carbon steel base with spill containment and piped in carbon steel SCH40 […]
Check out these Mouvex H-FLO 25 eccentric disc pump skids we designed for a manufacturer of antiseptic products to pump glycerin. The skid incorporated the Mouvex pump, a Nord gear reducer and a Baldor white washdown motor all mounted on a stainless steel sanitary base plate we fabricated (including welding) at our facility. As you […]
Pictured is a skid designed to transfer batches of Glycol off rail cars and into tanker trucks. To achieve this, a Blackmer MS3 Magnes pump was coupled to a Nord gearbox and a WEG 10 HP explosion proof motor. This assembly pumped the Glycol through an Endress Hauser ProMass Coriolis flow meter to totalize the […]
This water tempering skid was designed for an aerosol and bag on valve filling manufacturer. The manufacturer needed a way to heat up 194 gallons of batch water in their pressurized tank (able to fill 75 cans per minute), so they could test their product can’s integrity at 135 degrees Fahrenheit. The water tempering skid […]
This paint mixing and transfer skid was designed for a manufacturer of radiators that are used to cool large transformers. Our customer wanted to be able to efficiently mix paint and other chemicals to produce the protective outer coating that is applied on their radiators. Our engineered solution consisted of two Tuthill Global Gear pumps […]
This fuel filtration skid was designed to filter underground fuel storage tanks that have become dirty/contaminated or contain large amounts of water. Our customer was wanting to pull up to fueling stations and have the ability to clean out their in-ground tanks with a variety of filtration capabilities. The final product is one of the […]
We custom fitted a 1ā Wilden Stainless Steel FDA pump on a heavy-duty stainless steel hand cart with an RTI filter regular and Continental hose for the air input to the pump. This Wilden Full Stroke Diaphragm pump was used to transfer FDA Oils and Ingredients. It was built on a cart to optimize it […]
Resins are naturally occurring as a plant substance but are often made synthetically, converted into polymers to be used in numerous applications. When pumping certain resins the biggest factor to consider is their viscosity, as they can vary from a thin syrup to a solid substance. Resins can be difficult to handle as they can […]
When it comes to energy production, water plays a crucial role. Used as the main cooling source, it is a critical component in how these complex systems operate. Organic and inorganic substances in water create dissolved solids that along with other pollutants can cause buildup and corrosion. High-quality filters with high micron filter media, that […]
