Pickling filtration skid

Pickling Acid Filtration Skid

We built two custom filtration skids, each featuring two Wilden P200 AODD pumps, two FTI housings, two Orange Research differential pressure gauges, a Tudertechnica hose for vibration dampening, Dixon ball valves and a wall-mounted control panel built by our Michigan branch. The skids, which are used to filter an acid used in the pickling process, […]

Read More »

filtration skid

Portable Paint Manufacturing Filter Cart

We mounted an FTI (Filter Technology Incorporated) stainless steel filter housing on a stainless-steel fabricated cart. This allows the filter cart to be moved around the plant during the manufacturing of paint. The customer wanted the filter housing mounted on an angle to make changing the filter bags easier.

Read More »

Railcar to truck unloading system

Railcar to Truck Unloading System

This is a unique railcar-to-truck unloading system with Benko Products Fall Protection. The trailer mount is portable and can be moved along uneven terrain, which makes it practical for this type of unloading. The Blackmer MAGNES Seal-less 3″ vane pump, powered by a WEG motor and driven by a NORD Gear Reducer, can fill methanol (120 […]

Read More »

Xylem Pressure Control Skid

We built this pressure control skid featuring a Goulds Water Technology NPE pump, Aquavar variable speed pump controller, a HydroPro surge tank and Dixon Valve ball valves. Built to control and pump water at consistent pressure, the skid is mounted on painted carbon steel C-Channel base plate with lifting lugs and piped with SCH40 pipe.

Read More »

Double Gasoline Bowser

We built this custom 50-gallon gasoline bowser for an automotive customer. The portable cart is powder-coated stainless steel with large rubber wheels to make portability easy. The bowser has two internal walls to minimize heat loss from hot gas to cold gas. This bowser has two Wilden Pro-Flo Shift 1/2″ AODD pumps, ContiTech Flexsteel gasoline […]

Read More »

Blackmer G-Series Marshmallow Pump

Here is a Blackmer G1-55 pump skid for pumping marshmallow fluff at a candy manufacturing facility. The stainless steel Blackmer gear pump has 2.5” ANSI flanges and is powered by a 5HP Weg washdown duty motor connected to a Sew-Eurodrive Gearbox. The Blackmer G1-55 pump has a nominal flow capacity of 90 GPM and 150 […]

Read More »

Gas Driven Compressor Packages

This compressor skid has a Mouvex Pump compressor coupled to a NORD gearbox driven by a Honda gas engine. The skid will mount on tanker trailers to compress the tanker and push the product off the trailer. Normally these compressors are mounted on the trucks and PTO driven, but mounting them on the trailer provides […]

Read More »

Custom Ampco AL Series Pump

This is one of many Ampco Pumps AL Series pump skids we supplied for a customer that pumps food grade oil at a processing facility. Notice the custom inlet and discharge extensions, which meet the customer’s specifications, and an Ampco Stainless Steel Lobe pump with NORD Helical Inline Gear Motor (painted white). The components are […]

Read More »

Graco Quantum Pump on Cart

No compressed air? No problem! Check out this cost-saving cart-mounted Graco QUANTM i30 electric double diaphragm pump we provided to a custom film and adhesive developer. The assembly enables the company to pump chemicals in an area of the operation where compressed air is not available. Features of this pump cart include: • 1″ NPT […]

Read More »

Xylem Filter Skid

This filter skid featured a Xylem (Goulds Water Technology) NPE pump, FTI filter housing using AJR high-capacity oil absorbing micro-fiber filter media, and Dixon ball valves. Made for a Truck Accessory Manufacturer, we mounted the pump and filter on a stainless-steel double bend base and connected the two using welded SCH40 stainless steel piping. The […]

Read More »
